Moog Labyrinth

Moog Labyrinth, a semi-modular instrument and a true idea machine, explores familiar and unfamiliar patterns, layers and textures. Two generative sequencers bring sounds to life that unfold over time. You have control over their development and scope to merge them into striking polymetric melodies. Thanks to its parallel analog signal paths, this unique instrument can fill the static background of a drum pattern or bassline with color. Labyrinth can stand alone or expand your existing rack and is equally at home in a live set or at the center of a small home studio. Moog Labyrinth is the spark that takes a studio session deep into unexplored creative caves.

At the heart of Moog Labyrinth is a robust dual sequencer that uses random operations to create two unique eight-stage paths that wind around each other to form a mesmerizing path of sound. With an extensive patchbay, the Moog Labyrinth can be synchronized via analog clock or MIDI while controlling, influencing and being controlled by other devices.

Tune your instruments to each other and let Moog Labyrinth improvise in key while you play the Matriarch. Combine Labyrinth with Spectravox for animated spectral movements. Integrate Moog Labyrinth with Mavis in a 104HP rack for extended modularity. These are just a few of the many creative setups where Moog Labyrinth fits perfectly. Whichever path you choose, let Moog Labyrinth inspire you.

Features:

• Sources: VCO, MOD VCO, RING MOD, NOISE Generator
• Signal processors: 1x voltage-controlled wavefolder, 1x voltage-controlled state-variable filter, 2x voltage-controlled amplifiers
• Modulators: 2x decay-only envelope generators
• 2x 8-stage generative digital sequencers
• Connectors: 32 x 3.5 mm
• Inputs: 20 input sockets
• Outputs: 12 output sockets
• Audio: 1⁄4" TRS headphones or 1⁄4" TS instrument
• Power: Power supply connection
• Security: Kensington Lock slot
• Power consumption: 4.0 W
• Current consumption: 290 mA (maximum) from +12VDC (10-pin header)
• Installation dimensions: 60HP (18 mm module depth)
• Weight: 1.5 kg
• Dimensions (WxDxH): 32.61 x 14.33 x 10.67 cm

Scope of delivery:

• Labyrinth Semi-Modular Parallel Generative Analog Synthesizer
• Power supply unit
• Patch sheet overlays
• Patch cable (5x 12")
• Registration card
• Quick Start Guide
• Cheat codes

Specs:

• Color: Black
• USB-MIDI: n.s.
• MIDI Inputs: 0 Ports
• MIDI Outputs: 0 Ports
• Type of sound generation: Analogue
• Type: Synthesizer
• Theme: Recording and Studio

Instruction manual / Safety instructions:

• Manual (15.62 MB)

Downloads:

• Booklet (7.22 MB)
